EMU Black med 2JZ+vvti Ledingsnett

18.993,- NOK (inkl. mva)

19.993,- NOK Ikke medlem: 18.993,- NOK

15.195,- NOK (eks. mva)

15.995,- NOK

SKU: EMUBLCK-2jzhardness-1

Bestillingsvare .

Del produkt på

Produktinformasjon

ECUMaster Black inklusive Ledningsnett for 2Jz and 2Jzvvti

Basic net:

Audi cop coils

EV1

TPS

VVTI

BOOST

IAT

CRANK

CAM

FUEL PRESSURE

OIL PRESSURE

CLT

Deutch connectorx6 pin:3xAnalog 1x+5V 1xAUX 1xsensor ground

RELE socket for FAN,MAIN.FUEL and COILS

GENERAL
Enclosure protection	IP 60
Temperature range	AECQ100 GRADE3 (-40 to +85C)
Reverse battery protection	Yes, internal
Operating voltage	6-20V, immunity to transients according to ISO 7637
Operating current (ECU)	< 0.5A
Size (mm)	155x120x45
Weight (g)	500
Connectors	2 x 24 FCI Automotive connector
Communication	USB (with PC client software), serial or CAN
OUTPUTS
Injector outputs	6 protected outputs 5A, low side
Ignition outputs	6 outputs 7A(15A peak) (passive&active coils supported)
Aux outputs	6 protected outputs 5A, low side
Stepper outputs	Full bridge up to 0.8A, can be used as separate outputs
WBO heater	Protected low side up to 5A
+5V	1
CAN BUS	Yes with additional module
Serial	Yes
INPUTS
Analog inputs	7, 10Bits, 0-5V, 4 additional analog inputs with CAN module
EGT inputs	2 for K-Type thermocouple
Knock sensor	2
Oxygen sensor	LSU 4.2 or Narrow band
Trigger inputs	3 (primary, 2 cams) Hall/ VR software selectable
VSS	1 (Hall / VR)
Flex Fuel	Using CAM#2 or VSS
SENSORS
Temperature sensors	IAT, CLT, Oil temperature (user defined characteristic), AC evap temperature
Pressure sensor	MAP, Oil pressure, Fuel pressure (user defined characteristic), AC pressure sensor
Òxygen sensor	LSU 4.2 (built in controller), Narrow band, external WBO controllers
Speed	Vehicle speed sensor (VR/HALL), Gear sensor (sensor, calculated)
FUELING
Injectors	Up to 6 Hi Z injectors (sequential)
Battery compensation	User defined, wizard for popular injectors
Fueling strategies	VE based speed density, Alpha N
Air charge temp.	Based on IAT and CLT
VE table	2 tables 16×20 (Load x RPM), resolution of 0.1%
Individual cylinder trim	Yes
Staged injection	Yes
Additional correction	EGT correction (per cylinder), BARO, TPS vs MAP, TPS vs RPM, Warmup, Nitrous, LC, ALS, ASE, Fuel pressure, Knock sensor
Lambda based real time correction	Using Lambda/AFR target table
Acc. / Deceleration enrichment	Yes
IGNITION
Ignition outputs	6 for passive and active coils (software selectable)
Supported triggers	N-1, N-2, N-3, N+1, Multitooth, Subaru triggers, Nissan trigger, Lotus Elise, Audi trigger, Renault Clio Wiliams / Alpine, Colt 1.5CZ
Ignition angle table	2 tables 16×20 (Load x RPM), resolution of 0.5 Deg
Per cylinder trim	Yes
Dwell time battery compensation	Used defined, wizard for popular coils
Odd fire compatibility	Application dependent
Additional correction	CLT, IAT, TPS vs MAP, Nitrous, Idle, Knock sensor, LC, Pit limiter, ALS, Flat shift, Timers, Acc. enrichment
KNOCK SENSING
Channels	2
Resonant frequency range	1-20kHz, 3^rd order AAF
Sampling	Ignition event driven, knock window
Actions	Ignition retard, fuel enrichment, dashboard indication
IDLE CONTROL
Control type	PWM solenoids (2,3 wires), drive by wire, stepper motors (bi and unipolar), ignition cut, fuel cut
Control strategy	Open / Close loop , ignition angle control
VE correction	Yes, for Alpha-N
Corrections	AC clutch, coolant fan, analog input
BOOST CONTROL
Boost ref and target tables	2 sets 16×20 (TPS vs RPM)
Control strategies	Open / Closed loop (PID based)
Corrections	Gear, VSS, IAT, EGT
DRIVE BY WIRE¹
Control strategy	Advanced 3D PID + static friction compensation
Supported throttles	All with DC motor and current requirement lower than 6A Wizard for 28 popular electronic throttles
PPS to throttle position characteristic	3D table
BLIP support	Yes
ALS support	Yes
TRACTION CONTROL
TC strategy	Delta RPM, gear compensation
Torque reduction	Spark cut using 3D table (16×20)
Sensitivity control	10 position rotary switch
VARIABLE VALVE TIMING
Supported systems	VVTi, MiVec, VANOS, Double Vanos
Number of camshafts	2
Control strategy	PID based closed loop, CAM angle target tables 12×12
FLEX FUEL
Ethanol content measurement	Yes
Fuel temperature measurement	Yes
Tables blending	VE, IGN, Lambda/AFR, Boost, Cranking fuel, ASE, Warmup
Fuel temperature PW correction	Yes
SPORT
ALS	2 independent ALS setting, DBW support
Shift light	Per gear shift light
Launch control	Yes
Gear cut	Yes (Open loop), DBW blip supported Source: Switch, load cell, CAN
Pit limiter	Yes
Rolling anti lag	Yes
ENGINE PROTECTION
Fail safe values for critical sensors	Yes
Dashboard indication of failures	Yes, user defined
Over temperature engine protection	Yes, user defined, RPM limit
Low oil pressure protection	Yes, user defined, shut off
Fuel pressure protection	Yes, fuel dose compensation, RPM limit, engine shut off
High exhaust temperature	Alarm, per cylinder fuel trim, boost limit
CAN BUS²
CAN standard	2.0A 125, 250, 500, 1000 kBps 11, 29 bits
Supported CAN Dashes³	ECUMASTER, Motec M800 Set 1, Haltech E8 E11v2, Pectel SQ 6, AEM
Supported OEM CAN streams³	BMW E46, Citroen C2, Mazda RX8, Ford ST, Polaris RZR, Mini Cooper R53, Fiat 500, Renault Clio, Lotus, Ford Fiesta, Ford ST
OTHER
Unused injection outputs can be used as AUX output	Yes
Unused ignition outputs can be used as AUX output	Only for some functions
Output functions	Fuel pump, coolant fan, parametric outputs, nitrous control, PWM 3D table output, AC clutch, main relay, speedometer, tachometer
Password protection	Yes, 2 levels
Timers	Fuel, Ignition, Boost, timers controlled by virtual outputs
Serial dashboard support	AIM, RaceTechnology
Autotune	Yes
Built in trigger scope	Yes
Logging	Real time logging to PC computer, logging on external loggers (serial / CAN)
